HyperFilter

Photonic Filter Module

In modern quantum optics experiments, we need to extract single-photon-level signal light from a large number of noise background. However, the frequency of noise is very similar to the frequency of signal, and the frequency difference usually is only a few GHz, or even a few hundred MHz. The spectral resolution of the well-known grating and band-pass filter is not high enough, and the filter extinction ratio and stability based on the Mach-Zehnder Interferometer (MZI) are not good enough. Although the resolution of the filter based on the Fabry-Perot Interferometer(aka. etalon) is sufficient, due to various technical difficulties, there are almost no commercial filters that can take into account all aspects: spectral resolution, extinction ratio and System stability. This has become a major problem in quantum optics experiments. Many graduate students have to spend a lot of precious time to build and debug filter systems. The photon filter module is a new product independently developed by the company based on the Fabry-Perot Interferometer. It supports multiple input and multiple output of optical signals, taking into account spectral filtering and spatial mode filtering, and realizes both filtering and frequency division functions. It has the advantages of high transmittance, strong denoising ability, high frequency division accuracy and stable performance. It is especially suitable for weak light signal extraction and fine spectrum analysis in different scenes.

Stable

Anti Noise

High-precision

High transmittance

01 - Configuration 02 - Features 03 - Applications

Configuration


Fabry–Pérot cavities

Light Alignment

Optical Board

Shock absorbers

Temperature Controller

Integrated chassis

01 - Configuration 02 - Features 03 - Applications

Features


Bandwidth

10MHz ~ 3GHz

Spectrum

350nm ~ 1700nm

Transmittance

The peak transmittance of a single filter cavity is 95%
the peak transmittance of three filter cavities in series is 70%

Extinction ratio

Single filter cavity>103:1
three filter cavity in series, total extinction ratio>107:1

Filter cavity temperature control

Temperature fluctuation after automatic locking <±3mK

Vibration damping base

Effectively isolate vibration over 50Hz

01 - Configuration 02 - Features 03 - Applications

Applications


  • Use standard tools to calibrate the frequency of light waves, filter out noise, and separate useful photons of different frequencies
  • Bioweak signal detection, fine analysis of aeroengine flame spectrum
  • Demonstration and teaching of quantum optics, quantum computing, quantum communication and other scientific experiments
  • Suitable for weak light signal extraction and spectral fine analysis in materials science, aerospace industry, biomedical imaging, etc.
